KXLS-AS01 Fully Automatic Single-Arm Single-Axis Winding Machine
Machine Configuration
|
Serial No. |
Item Specification |
Unit |
Quantity |
|
1 |
Rotation Speed: 3000RPM, 400W |
Set |
1 |
|
2 |
Eight-Axis Control Motion System |
Set |
1 |
|
3 |
Servo Motor |
Piece |
7 |
|
4 |
Weinview Inch Touch Screen |
Piece |
1 |
|
5 |
Sleeve Hook |
Set |
1 |
|
6 |
Motor Drive Pipe & Wire Threading Mechanism |
Set |
1 |
|
7 |
XYZ Axis Module (Imported Guide Rail & Lead Screw) |
Set |
3 |
|
8 |
Wire Break Alarm Device, Initial PIN Detection Device |
Set |
1 |
|
9 |
Tape Alarm Device, Initial PIN Detection Device |
Set |
1 |
|
10 |
Traction Encapsulation Device |
Set |
1 |
|
11 |
Pneumatic Cutter |
Piece |
2 |
|
12 |
Tensioner (Tension Attenuation) |
Set |
5 |
|
13 |
Linear Vibrator |
Set |
2 |
|
14 |
Automatic Material Receiving Track |
Set |
1 |
|
15 |
Winding Shaft Core |
Piece |
1 |
|
16 |
Star Air Cylinder + Solenoid Valve |
Batch |
1 |
|
17 |
Feeding Linear Vibrator |
Set |
1 |
|
18 |
Blanking Linear Vibrator + Fixture (Flat Laying) |
Set |
1 |
|
19 |
Opening/Closing Hook Steel Guide Needle |
Piece |
3 |
|
20 |
Right-Angle Pressing Device |
Set |
1 |
|
21 |
Wire Feeding Device |
Set |
1 |
|
22 |
Tool Kit |
Set |
1 |
Packaging
Packaging Material: Carton/Wooden case with foam inside.
1. General package(Paper carton or plastic bag): For small equipped parts for Digital CNC Wire Coil Winding Machine, Package it with form and pack paper to guarantee unbroken during the transport.
2. Wooden case package: For larger scale Digital CNC Wire Coil Winding Machine ,we have special skilled carpenter, who would make the proper wooden case with exact thickness, density,length. The up arrow ↑marked on the outer wooden case. Buffer material would be put in the wooden case to prevent crack and shock.
Market Area
We work closely with Southeast Asia, European, America, South America, Australia, New Zealand partners to provide local sales, support and service assistance for coil winding machines.
Factory
Founded in 1993, KIOXIA LIGHT RING EQUIPMENT GROUP CO.,LTD. has been a well-known manufacturing excellent performance winding machines together with associated production and technology. KIOXIA LIGHT RING provide highly cost effective manufacturing solutions for the production of the wound components of all types such as transformers,chokes etc.
