KXPC-870 SQ/UC Automatic Flat Copper Wire Vertical Winding Machine

Product Description

The KXPC-870 SQ/UC is a sophisticated vertical automated platform engineered specifically for the precision winding of flat-profile copper conductors. Designed to meet the rigorous demands of contemporary industrial fabrication, this system consolidates high-tier automation with exacting motion control. By utilizing a standardized autonomous discharge architecture, the machine minimizes manual oversight, stabilizes production cadence, and ensures mechanical uniformity across all workpieces. Integrated sensory circuits for trajectory deviations and material obstructions provide real-time operational security, while the high-torque, dual-spindle pay-off assembly guarantees a fluid material supply. Its space-efficient footprint and ergonomic interface make it a foundational utility for the manufacture of advanced electromagnetic components and propulsion systems.

Product Specifications

Electric Voltage	220V (single-phase, stable for continuous operation)
Power Rate	800W-1000W (energy-saving, stable transmission)
Machine Size	1500×1000×1200mm (L×W×H), compact and easy to install
Production Capacity	800-1000 pieces/hour (ordinary); 1500 pieces/hour (special), suitable for mass production
Equipment Weight	180KG, stable to ensure winding precision
Wire Diameter Range	Thickness 0.1-0.6mm, width 0.6-2.0mm, strong versatility
Optional Configuration	Automatic feeding and multiple material alarm functions, customizable for production needs

Features & Advantages

The technical architecture of the KXPC-870 SQ/UC delivers measurable improvements in yield stability, operational agility, and lifecycle cost management:

Exacting Dimensional Integrity: The system maintains a verified defect threshold of below 0.3%, achieving superior axial symmetry and a diameter tolerance of ±0.02mm. This is powered by an 8-axis imported servo transmission suite featuring active error compensation for stabilized execution.

Rapid Throughput and Setup: Conductor transitions are strictly controlled, requiring 5 minutes for single-head setups and 10 minutes for dual-axis reconfigurations. A "plug-and-play" modular tooling philosophy permits total model changeovers in under 30 minutes without the need for manual calibration.

Intelligent Logic Framework: A centralized HMI facilitates streamlined parameter management. Autonomous fault identification protocols ensure that recovery times are sustained at 5 minutes. Furthermore, the decoupled architecture between software logic and hardware execution safeguards the system against mechanical strain during continuous 24-hour duty cycles.

Sustainable Maintenance & Economic Utility: The hardware is designed for operator-level preventative maintenance, reducing reliance on specialized technicians. Low operational overhead is achieved through the integration of recyclable consumables and a high-durability structure that maximizes the mean time between failures (MTBF).

Proactive Safety and Supervision: In addition to standard winding and obstruction telemetry, the unit supports optional material-validation alarms, ensuring full compliance with industrial safety mandates and preventing catastrophic equipment damage.

Specific Applications

The KXPC-870 SQ/UC serves as a high-flexibility solution across the global electronics, automotive, and renewable energy sectors:

Electromagnetic Components: Ideal for the fabrication of high-performance inductors, transformers, and solenoid coils where stable electrical impedance is critical.

Motor Manufacturing: Optimized for stator and rotor winding in small-to-medium motor frames, enhancing power density and rotational consistency.

Automotive Systems: Facilitates the production of ignition coils and alternator assemblies, delivering the ruggedized reliability required for demanding vehicular environments.

Sustainable Energy Infrastructure: Specifically calibrated to meet the high-tolerance winding requirements of EV propulsion motors and large-scale energy storage transformers.

Specialized Engineering: Provides the necessary precision for aerospace actuators and telecommunications hardware, demonstrating extreme versatility across high-tech domains.
