Product Overview
Our Fully Automatic Multi Axis Winding Machine is a high-precision, high-efficiency industrial solution designed for mass production of precision coils. Engineered with advanced CNC and servo control systems, it automates the entire winding process-from wire feeding and precise winding to tape wrapping, wire cutting, and unloading. It is the ideal equipment for manufacturing transformers, inductors, solenoids, and various electronic coils.
Key Features & Advantages
Multi-Spindle High-Speed Parallel ProductionAvailable with 4, 6, 8, 12, or 16 independent spindles. All axes work simultaneously to drastically increase output, achieving unparalleled production efficiency compared to single-axis machines.
Fully Automated WorkflowIntegrates automatic bobbin loading, precise wire tension control, CNC winding, interlayer & end tape wrapping, wire stripping & cutting, and finished product unloading. Requires minimal operator intervention, reducing labor costs and human error.
Superior Winding PrecisionDriven by high-performance servo motors. Delivers micron-level accuracy in wire positioning, ensuring tight, uniform, and cross-free winding. The intelligent system maintains consistent tension for flawless coil quality.
User-Friendly Intelligent ControlFeatures an easy-to-use HMI touchscreen interface. Stores up to 999 sets of winding programs. Quick product changeover is achieved by simply recalling a pre-set program. Supports both Chinese and English languages.
Versatile & FlexibleAccommodates a wide range of wire diameters (0.025mm–0.8mm) and bobbin sizes. Capable of complex winding patterns, including multi-layer, right-angle, and reverse winding.
Stable & Reliable ConstructionBuilt with a heavy-duty cast structure for maximum rigidity and long-term stability. Equipped with comprehensive safety protections and real-time alarms for wire breakage, tape shortage, or abnormal operation.
Technical Specifications (Standard Model)
| Parameter | Details |
|---|---|
| Number of Spindles | 4/6/8/12/16 |
| Spindle Speed | Up to 12,000 RPM |
| Applicable Wire Diameter | 0.025 – 0.8 mm |
| Control System | CNC / Servo Motor Control |
| Power Supply | AC 220V, 50/60Hz |
| Dimensions | Customizable |
Applications
Widely used in the mass production of:
Electronic Transformers (Power, High-Frequency, Pulse)
Inductors & Choke Coils
Relays & Solenoid Valves
Telecom & Automotive Coils
